515: Moteur - Système de graissage - Ventilation de carter supérieur
(2006 - 2010 | 4-CYL,DIESEL)
| Pos. | Réf. | Qté | |
|---|---|---|---|
| 1 | 93179199 55217793 Capteur huile Usage: 2006-2007 | 1 | |
| 1 | 55192366 Déshuileur Usage: 2006-2007 | 1 | |
| 1 | 55217795 Déshuileur Usage: 2008-2010 | 1 | |
| 2 | 93179200 Flexible | 1 | |
| 3 | 93179201 Collier serrage Usage: Ø24 MM | 2 | |
| 4 | 55199390 Flexible | 1 | |
| 5 | 93179203 Console | 1 | |
| 6 | 93179204 Collier serrage | 1 | |
| 7 | 93179205 Rondelle | 3 | |
| 8 | 93183430 Vis Usage: M5X12 | 3 | |
| 9 | 93179207 Collier serrage Usage: Ø20,5-22,5 MM | 2 | |
| 10 | 93177489 Vis Usage: M6X14 | 1 | |
| 10 | 93177417 Vis Usage: M6X22 | 1 | |
| 11 | 55574449 Ecrou raccord | 1 | |
| 12 | 93179209 Collier serrage Usage: Ø26 MM | 1 | |
| 13 | 93179210 Ecrou Usage: M6 | 1 | |
| 14 | 55559053 Tuyau Usage: 2006-2006 | 1 | |
| 14 | 55566851 Tuyau Usage: 2007-2009 | 1 | |
| 15 | 55559058 Tuyau | 1 | |
| 16 | 55559059 Flexible | 1 | |
| 17 | 55559060 Flexible | 1 | |
| 18 | 55559063 Fixation | 1 | |
| 19 | 55559056 Fixation | 1 | |
| 20 | 90499093 Collier serrage | 2 | |
| 21 | 92152409 Collier serrage | 2 | |
| 22 | 55351569 Flexible | 1 | |
| 23 | 90572594 Collier serrage | 1 | |
| 24 | 90467194 Collier serrage | 1 | |
| 25 | 90530642 Collier serrage | 2 | |
| 26 | 11900512 Ruban serrage | 2 | |
| 27 | 55565118 Baffle Usage: 2007-2010 | 1 | |
| 28 | 93184683 Flexible Usage: -2001 | 1 | |
| 28A | 55207543 Flexible Usage: 2001- | 1 | |
| 28B | 55209237 Flexible Usage: 2001- | 1 | |
| 29 | 55567315 Obturateur Usage: Ventilation de carter supérieur Tuyau | 1 |
